43”curved 4K Monitor

Capacitance-touch technology

Kontech curved touch display is a kind of touch display product designed for games, high-end places and gambling, such as self-service terminal, game machine, gambling machine, etc. The utility model has the advantages of compact structure, convenient installation and high cost performance. All products adopt multi-point projection capacitance touch technology, which has the characteristics of fast touch response, high precision and strong anti-interference.

Details Parameters Application

curved monitor

curved monitor

4K curved monitor

Product Name

43”curved 4K Monitor with capacitance-touch technology

Size

43 inches

LCD Panel

Display Area

963.6(H)×557.9(V)mm

Aspect Ratio

16:9

Backlight

LED

Backlight life

>50000h

Resolution

3840×2160

Lightness

300cd/㎡

Contrast Ratio

1300:1

Video Response time

8ms

Dot Pitch

0.2451(H)×0.2451(V)mm

Color

16.7M

Viewing Angle

Horizontal/Vertical:178°/178°

Capacitive Screen parameters

Touch Scheme

Projected G+FF capacitive touch technology

Touch Response Time

 <5ms

Touch Points

Standard 10-point touch (can realize image zoom out and enlargement, etc.)

Touch Effective Recognition

>1.5mm

Scanning Frequency

200HZ

Scanning Accuracy

4096 x 4096

Communication Method

Full speed USB2.0,USB3.0

Theoretical Clicks

More than 50million

Working Current/Voltage

180Ma/DC+5V+/-5%

Anti-light Interference

Normally display when the strong light of sunlight, incandescent lamp and fluorescent lamp changes.

Touch Data Output Method

Coordinate output

Surface hardness

Physically toughened, Mohs grade 7 explosion-proof glass

Operating System Compatibility

Android/Windows

Drive

Drive-free, plug and play

External Interface

HDMI1.4 Input

HDMI2.0 Input

1

Touch USB

1

Headphone Output

1

AC Power

1

Power Supply

Power Supply

AC220V  50/60Hz

Maximum Power Consumption

135W

Standby Power Consumption

0.8W

Operating Environment

Temperature

0~40℃

Humidity

10~90%RH  No condensation

Appearance

Product Dimensions

980.9*572*127.4mm

Carton Dimensions

1100*705*245mm

Net Weight

23.95KG

Gross Weight

26.8KG

Accessories

Power cord*1, HDMI cable*1,Touch USB cable*1,Remote control*1
